84.5", VA, 4K UHD (3840 x 2160), 350 nit, 4000:1, 178/178, 10 ms, WiFi, Bluetooth, RJ-45, HDCP, HDMI, RS232, AC 100-240V, 50/60Hz, 1904.3 x 1085.3 x 28.5 mm, 41.9 kg
Specifications
| to show |
| Panel type | VA |
| Display diagonally | 2.15m (84.5") |
| Display technology | LCD |
| Screen resolution | 3840 x 2160 pixels |
| Brightness of the display | 350 cd/m² |
| HD type | 4K Ultra HD |
| Touch screen | No |
| Response time | 10 ms |
| Contrast ratio (typical) | 4000:1 |
| Dynamic Contrast Ratio Marketing Name | Mega contrast |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.487 x 0.487 mm |
| Horizontal scan range | 30 - 81 kHz |
| Vertical scan range | 48 - 75 Hz |
| Haze rate | 2% |
| Pixel frequency (max) | 594 MHz |
| RGB color space | NTSC |
| Ports and interfaces |
| HDMI port quantity | 3 |
| HDMI version | 2.0 |
| Number of HDMI input ports | 3 |
| DVI port | No |
| USB port | Yes |
| Number of USB ports | 2 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | Yes |
| RS-232 interface | Yes |
| Infrared data port | Yes |
| External (IR) input | 1 |
| Design |
| Product design | Digital signage flat panel |
| Placement supported | inside |
| Product color | Black |
| Screen shape | Right |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 1.39 cm |
| Bezel width (side) | 1.39 cm |
| Design |
| Bezel width (top) | 1.39 cm |
| Color border | Charcoal Black |
| Mounting type | Wall |
| performance |
| Goal | universal |
| Operating hours (hours/days) | 16/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| power |
| Power consumption (typical) | 231 W |
| Power consumption (sleep) | 0.5W |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Energy efficiency scale | A to G |
| Computer system |
| Computer system | Yes |
| Type of computer system | System on Chip (SoC) |
| Built-in processor | Yes |
| Operating system installed | Tizen 7.0 |
| Weight and dimensions |
| Width display | 1904.3 mm |
| Show depth | 28.5 mm |
| Show height: | 1085.3 mm |
| Show weight | 41.9 kg |
| Packaging details |
| Package width | 2077 mm |
| Package depth | 210 mm |
| Package height | 1222 mm |
| Package weight | 53.9 kg |
| Operational conditions |
| Operating temperature (TT) | 0 - 40 ° C |
| Relative humidity in operation (HH) | 10 - 80% |
| Technical details |
| Audio output (mini jack) | 1 |
